Cooler Specification
Socket compatibility AMD AM4
Height (without fan) 160 mm
Width (without fan) 150 mm
Depth (without fan) 135 mm
Height (with fan) 165 mm
Width (with fan) 150 mm
Depth (with fan) 161 mm
Weight (without fan) 980 g
Weight (with fan/s) 1320 g
Material Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Max. TDP see TDP guide
Fan compatibility 140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25
Scope of delivery
2x NF-A15 PWM premium fan
2x Low-Noise Adaptor (L.N.A.)
4-pin PWM y-cable
NT-H1 high-grade thermal compound
SecuFirm2™ AM4 mounting-kit
Noctua metal case-badge
Warranty 6 Years
FAN Specification
Model 2x Noctua NF-A15 PWM
Bearing SSO2
Max. Rotational Speed (+/- 10%) 1500 RPM
Max. Rotational Speed with L.N.A. (+/- 10%) 1200 RPM
Min. Rotational Speed (PWM, +/-20%) 300 RPM
Max. Airflow 140,2 m³/h
Max. Airflow with L.N.A. 115,5 m³/h
Max. Acoustical Noise 24,6 dB(A)
Max. Acoustical Noise with L.N.A. 19,2 dB(A)
Input Power 1,56 W
Voltage Range 12 V
MTTF > 150.000 h
