Cost saving- Power and video over single UTP cable
Perfect for analog security systems
Easy installation
Passive video transmission set for video and power
Uses single Cat5 UTP cable
Up to 300 m transmission distance using Cat5 cable
Passive, no external power supply required
Connectors: BNC (video), RJ45 (UTP), 5.5 x 2,1 mm jack/plug (power)
Video impedance: BNC:75 Ohms / UTP: 100 Ohms
CMRR: 60 dB
Attenuation: 0.3 dB
UTP type: CAT5 24 AWG
UTP impedance: 9 Ohms (100 m)
Power: max. 24 VDC
Working Temp:-10°C~+50°C (humidity 0~95%RH)
Storage Temp:-30°C~+70°C (humidity 0~95%RH)
Dimensions: 43 x 22 x 22 mm
Weight: 60 g. (pair)
