Type motherboard
EAN 4712900552874
Manufacturer no. 90MB0QY1-M0EAY0
processor designation Rockchip RK3288 quad-core processor
form factor proprietary
use PC
power adapter external
Storage available 2 GB
Terminals (external) USB 2.0 4
RJ-45 1
Bluetooth Yes
Connections (internal) 4-pin PWM fan 2
graphic ARM® Mali ™ GPU -T764
sound RTL ALC4040
LAN Realtek Gigabit LAN
Wi-Fi 4 802.11 b / g / n
Heatpipe cooling Yes
features Micro SD (TF) card slot | 1x 40-pin header: up to 28 x GPIO pins, up to 2 x SPI bus, up to 2 x I2C bus, up to 4 x UART, up to 2 x PWM, up to 1 x PCM / I2S, 2 x 5V power pins, 2 x 3.3V power pins, 8 x ground pins | 1 x 2-pin contact pin: 1 x PWM, 1 x S / PDIF, 1 x 15-pin MIPI DSI, 1 x 15-pin MIPI CSI
equipment available Passive radiator, user
Dimensions Width: 86 mm x height: 54 mm
mass 55 grams
