Intel® compatible Sockets LGA 775, 115x, 1366, 2011(-3) Square ILM, 2066
AMD® compatible Sockets FM1, FM2(+), AM2(+), AM3(+), AM4
Overall Dimensions 144.2 x 109.5 x 163mm
Overall Hight
160mm
Weight without Fan
864g
Thermal Design Power (TDP) 230W+
Thermal Grease Dow Corning® TC-5121
Dimensions
135.2 x 65 x 160mm
Material
Copper Heat Pipes/ Aluminium Fins
Heat Pipes
5x Ø 6mm
Heat Sink Coating
TCC black
Fan Model High Pressure Blade Fan PWM
LED –
Bearing Type
Twister Bearing
MTBF 160,000h
Fan Dimensions
140 x 140 x 25mm
Fan Speed
500 – 1,000 RPM
Rated Voltage
12V
Connector
4-pin PWM
Quantity 1
Noise Level
13 – 22dB(A)
Air Flow
50.59 – 55.45m3/h
Air Flow
29.78 – 94.21CFM
Static Pressure
0.57 – 2.13mm-H2O
