Product Name :
Hot-Swap 3.5" / 2.5" SAS & SATA HDD Backplane Module
Model Number :
MB153SP-B
Color :
Black
Support Drive Size :
3.5" HDD
Compatible Drive Type :
SATA / SAS (Support Single Channel SAS)
Number of Drives :
3
Max Drive Height :
26.1mm
Drive Bay :
2 x 5.25" Device bay
Host Interface :
3 x 7pin SATA
Power Input :
2 x 15 pin SATA power connector
Transfer Rate :
Up to 6Gbps (Depending on hard drive speed)
Support HDD Capacity :
No Limitation
Drive Cooling :
80 x 80 x 25mm Fan
RAID Function :
N/A
Structure / Material :
Metal body with partial plastic
Support Hot-Swap :
Yes
Drive Security :
N/A
Product Dimension (L x W x H) :
200.4 x 146.4 x 85.8mm
Product Weight :
912g
Shipping (Package) Weight :
1210g
RAID Status LED Indicator :
N/A
Drive Activity LED Indication :
Drive power: solid green; HDD access: flashing green
Package contents :
1 - Device, 1 - user manual, 32 - screw
Product Name :
3 x 3.5” HDD in 2 x 5.25” Bay Hot Swap SATA 6Gbps HDD Rack/ Cage/ Module
SATA Connector Insertion Rate :
10,000
Humidity :
5%~65% RH
Opertating Temperature :
0°C to 60°C (32°F to 140°F)
Storage Temperature :
-35°C to 70°C (-31°F to 158°F)
Compliance :
CE, RoHS, REACH
Warranty :
3 years
