Performance
AC Input: 230V / 3A
Frequency: 50 Hz
+5V: 15A
+3,3V: 14A
+5V & +3,3V combined: 80W
+12V 1: 18,5A / 220W
+12V 2: -
+12V 1 & +12V 2 combined: N/A
+12V 3: N/A
+12V 4: N/A
+12V 3 & +12V 4 combined: N/A
P.F.: >0,9
-12V: 0,3A / 3,6W
+5VSB: 3A / 15W
Maximum Load: 250W
Native cable
20+4PIN ATX: 1
SATA: 2
MOLEX: 2
Floppy: 1
4PIN 12V: 1
8PIN 12V: -
8PIN (4+4) 12V: -
6PIN PCIe: -
8PIN (6+2) PCIe: -
Features
Spezification: ATX 12V 2.3
Form factor: SFX
Efficiency: > 85%
Dimension (DxWxH): 100 mm x 125 mm x 64 mm
PFC: Active PFC (0,9) (only 230V)
Fan: 80mm silent fan
Security:
UVP (Undervoltage protection)
OVP (Overvoltage protection)
SCP (Short-circuit protection)
OPP (Overload protection)
AFC (Automatic Fanspeed Control)
SIP (Surge & Inrush Protection)
Warranty: 24 Month
