P/N PS-SPR-0500NHFAWx-1
Short P/N SPR-0500NHFAW
Model SPR-500AH2NK-1
Type Intel ATX 12V 2.3
Max. Output Capacity 500W
Color Black
Dimension (H x W x D) 86mm x 150mm x 140mm
PFC （Power Factor Correction） Active PFC
Power Good Signal 100-500 msec
Hold Up Time 16msec (minimum) within 60% load
Input Current 8A max
Input Frequency Range 50 Hz - 60 Hz
Input Voltage 100Vac – 240Vac
Operating Temperature 5℃ to +40℃
Operating Humidity 20% to 85%,non-condensing
Storage Temperature -40 ℃ to +55 ℃
Storage Humidity 10% to 95%, non-condensing
Cooling System 120mm Fan: 1800 R.P.M. ± 10%
Efficiency 82-86% efficiency @ 20-100% load
MTBF 100,000 hrs minimum
Safety Approval CE/CB/TUV/ UL/ FCC/ EAC
Protection OVP, OPP, SCP
