P/N CA-1I7-00F1WN-00
Case Type Full Tower
Dimension (H x W x D) 592 x 274 x 577 mm
(23.3 x 10.8 x 22.7 inch)
Net Weight 18.9 kg / 41.66 lb
Side Panel 5mm Tempered Glass x 4
(Left & Right & Front & Top)
Color Exterior & Interior : Black
Material SPCC
Cooling System Rear (exhaust) :
140 x 140 x 25 mm Riing LED Blue fan
(1400rpm, 28dBA) (1000rpm, 22 dBA with LNC)
Front (intake) :
140 x 140 x 25 mm Riing LED Blue fan
(1400rpm, 28dBA) (1000rpm, 22 dBA with LNC)
Drive Bays
-Accessible
-Hidden -
2.5” x 4 or 3.5”x4(HDD Rack)
2.5”x 6 or 3.5” x 3
Expansion Slots 8+2
Motherboards 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX), 12” x 13”(E-ATX)
I/O Port USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
PSU Standard PS2 PSU (optional)
Fan Support Front:
3 x 120mm , 2 x 140mm
Top:
3 x 120mm , 3 x 140mm
Rear:
1 x 120mm, 1 x 140mm
Bottom:
2 x 120mm
Radiator Support Front:
1 x 360mm , 1 x 420mm
Top:
1 x 360mm , 1 x 420mm
Rear:
1 x 120mm, 1 x 140mm
Right:
1 x 360mm, 1 x 420mm
Bottom:
1 x 240mm
Clearance CPU cooler height limitation:
190mm
VGA length limitation:
310mm(With HDD Rack)
410mm(Without HDD Rack)
PSU length limitation:
220mm (Without Bottom Fan)
