Specification
3.5" or 2.5" Drive capacity
2
Dedicated 2.5" drive capacity
3 (maximum 2.5" drive thickness is 12mm)
Expansion slots
7
Motherboard compatibility
ATX, mATX, ITX
Power supply type
ATX
Total fan mounts
7
Front fan
3x 120 or 2x 140
1x Dynamic X2 GP-12 included
Top fan
2x 120/140
Rear fan
1x 120
1x Dynamic X2 GP-12 included
Bottom fan
1x 120
Side fan
No
Dust filters
Bottom fan + PSU
Front fans
Top fans
Front radiator
120/240/360mm
140/280mm
Top radiator
120/240mm (max component height on motherboard 40mm)
Rear radiator
120mm (max width 125mm)
Power supply depth limit
Maximum 175mm recommended
Graphics card length limit
Max 315mm with front fan mounted
CPU cooler height limit
172mm
Cable routing
15-35mm space
Cable routing grommets
Yes
Fixed velcro straps
Yes
Captive thumbscrews
Right side panel
SSD brackets
Left side panel
Tempered Glass
Case dimensions (LxWxH)
395 x 212 x 440mm
Case dimensions - with feet/protrusions/screws
409 x 217 x 453mm
Net weight
6.5 kg
Package dimensions (LxWxH)
543 x 295 x 484mm
Package weight
7.9 kg
