watts 1200W
RGB Fan Yes
Model TPD-1200AH3FCP-A
Max. Output Capacity 1200W
Peak Output Capacity 1440W
Color Black
Dimension ( W / H / D ) 150mm(W) x 86mm(H) x 180mm(D)
PFC (Power Factor Correction) Active PFC
Power Good Signal 100-500 msec
Hold Up Time > 16m sec at 100% of full load
Input Current 14A
Input Frequency Range 50Hz - 60Hz
Input Voltage 100V – 240V~
Operating Temperature 0°C to + 50°C
Operating Humidity 20% to 90%,non-condensing
Storage Temperature -20°C to + 70°C
Storage Humidity 5% to 95%, non-condensing
Cooling System 14cm hydraulic bearing fan
Efficiency Meet 80 PLUS®Platinum at 115Vac input.
MTBF 120,000 hrs minimum
Safety Approval CE/cTUVus/TÜV/FCC/BSMI/CCC/EAC/S-Mark
PCI-E 6+2pin 8
Protection OCP, OVP, UVP, OPP, SCP, OTP
