Model CS-102
Case Type Mini Tower
Steel Thickness 0.4mm
Motherboards Micro ATX / Mini ITX
Case Dimensions 170mm x 345mm x 325mm (W x H x D, internal)
Case Dimensions 190mm x 345mm x 372mm (W x H x D, overall)
5.25” Drive Bays 1 (Exposed)
3.5"Hard Disk Drive Bays 3
2.5” Drive Bays 2
Expansion Slots 4
GPU Clearance 240mm
I/O Ports USB3.0 x 1, USB2.0 x 1, HD Audio & MIC
CPU Cooler Clearance
Supports Max. Height Of 150mm For CPU Cooler
Air Cooling System Left: 120mm fan x1 (Optional)
Rear: 80mm fan x1 (1 x 80mm Black Fan Included)
Net Weight/Gross Weight 1.9kg (4.2lbs.)/2.4 kg(5.3 lbs.)
Power Supply
Standard ATX PS/2 (Optional)
COOLING SYSTEM
CS-102 [ Rear ]
Black Edition
Fan 80 x 80 x 25 mm
Rated Voltage 12V
Operating Voltage Range 10.8~13.2V
Starting Voltage 8V
Power Consumption 0.84W+10%Max
Rated Current 0.07A+10%Max
Speed 1600+-10%RPM
Air Flow (CFM) 28CFM
Air Pressure 1.2mm-H2O
Noise (dBA) 25dBA
MTBF 20,000 hours
