Τροφοδοτικά

Type PC Power Supply EAN 4710007220221 Manufacturer no. SST ST50F-ES230 power total 500 W + 3.3V / + 5V total 110 W efficiency Up to 85% installation standard ATX12V 2.4 design ATX certification 80 PLUS 230V EU currents +3.3 V 18 A +5 V 17 A +5 Vsb 2.5 A -12 V 0.3 A +12 V Total 38 A +12 V1 38 A Power Factor Correction Active PFC connections 4x 15-pin SATA, 1x 20-pin ATX, 1x 24-pin ATX12V 2.x, 1x 4 + 4-pin 12V, 1x 4-pin 3.5 ", 3x 4-pin 5 , 25 ", 2x 6 + 2-pin graphics cooling Fans 1x 120 mm fan volume 18 dB (A) at 20% load protection functions Over voltage protection (OVP), overload protection (OLP / OPP), short circuit protection (SCP) Dimensions Width: 150 mm x height: 86 mm x depth / length: 140 mm mass 1.3 kg

P/N PS-TRS-0500NPCW**-2 Short P/N TRS-0500P-2 Model TRS-500AH2NK Type Intel ATX 12V 2.3 Max. Output Capacity 500W Color Black Dimension 86mm x 150mm x 140mm PFC （Power Factor Correction） Active PFC Power Good Signal 100-500 msec Hold Up Time 16msec (minimum) within 60% load Input current 8A max Input Frequency Range 50 Hz - 60 Hz Input Voltage 230 Vac Operating Temperature 5℃ to +40℃ Operating Humidity 20% to 85%,non-condensing Storage Temperature -40 ℃ to +55 ℃ Cooling System 120mm Fan: 1800 R.P.M. ± 10% Storage Humidity 10% to 95%, non-condensing Efficiency 82-86% efficiency @ 20-100% load MTBF 100,000 hrs minimum Safety Approval CE/CB/TUV PCI-E Connector PCI-E 6+2pin x 2

POWER SUPPLY ATX 550W Thermaltake LITEPOWER BLACK ATX power 550W Thermaltake LITEPOWER BLACK NON MODULAR FAN 120MM PS-LTP-0550NPCNEU-2

general Item TypeGaming BrandTHERMALTAKE Warranty2 years warranty Part numberPS-LTP-0550NHSANE-1 CategoriesPOWER SOURCES Volumetric Weight1.67 Kg. Connectivity Form factorATX Wiring typeFixed Power supply for motherboard24-pin ATX Floppy power connector1 Peripheral (4 pin) power connectors (Molex)4 PCI Express power connectors (6 + 2 pin)two CPU power connector (4 +4 pins)1 Number of SATA power connectors5 Weight and measurements Height86 mm Width150 mm Depth140 mm Technical details ColourBlack Power control Rated power550 W Type power factor correction (PFC)Active Input current7 a Maximum output current (+ 12V)38A Maximum output current (+ 3.3V)21 A Maximum output current (+ 5V)16 A Maximum output current (+ 5Vsb)2.5 A Maximum output current (-12V)0.5 A AC input frequency50 - 60 Hz Maximum energy550 W Combined power (+12 V)456W Combined power (+5 V)105 W Combined power (+5 VSB)12.5 W Combined power (-12V)6 W Combined power (+3.3 V)105 W AC input voltage230 V Cooling Fan diameter120 mm Number of fans1 Cooling typeActive Lighting / Alarms illuminationYes Environmental conditions Storage temperature range-40 - 60 ° C Operating Temperature Range5 - 55 ° C Packaging Content
